EXT-UHDV-WP-HBTLS-TX
0 €
Wall-mounted transmitter panel Gefen EXT-UHDV-WP-HBTLS-TX combines the functions of a scaler, switcher, and transmitter for HDMI and VGA signals with auto-switching. Supports resolutions up to 4K Ultra HD (4096×2160/30 with YUV 4:4:4, 3840×2160/60 with YUV 4:2:0) and VGA up to 1920×1200/60 with audio. Transmission is via CAT5e twisted pair cable using HDBaseT technology over distances up to 40 m (4K) and 70 m (1080p). Supports 3D, HDCP 1.4, EDID, CEC technologies, as well as bidirectional RS-232 and infrared control signals. The device provides bidirectional PoH (Power over HDBaseT) operation, control via RS-232, firmware updates via USB, and convenient wall mounting in a 2G USA box. Bandwidth 600 MHz.
Maximum power consumption: 15 W. Powered via PoH (Power over HDBaseT) technology from a compatible receiver/switcher.
